PCE Instruments Earth Resistance and Ground Tester (PCE-ET 3000)
PCE Instruments Earth Tester (PCE-ET 3000) is a professional tool designed for measuring earth resistance and ground voltage in electrical installations. Featuring a three-wire measuring method, this meter ensures accurate readings for residential, commercial, and industrial applications.
The earth resistance tester is equipped with an LCD display, battery status indicator, and data hold functionality. It meets IEC-1010-1 safety standards and includes a full set of test leads, earth rods, and batteries for immediate use.
Specifications and Dimensions
Measuring Ranges: Earth resistance: 0 … 19.99 / 0 … 199 / 0 … 1999 Ω
Resolution: 10 mΩ / 100 mΩ / 1 Ω
Accuracy: ± 2% + 2 digits
Voltage Measurement: AC 0 … 200 V (50/60 Hz)
Lower Measurement Limit: 0.01 Ω
Measurement Current: 2 mA RMS
Response Time: Approx. 2.5 seconds
Measurement Rate: Every 4 seconds
Operating Frequency: 820 Hz
Power Supply: 6 x 1.5V batteries
Dimensions: 160 x 120 x 65 mm
Standards Compliance: IEC 1010-1, EN 61010-1, DIN/VDE 0413
Key Features and Benefits
Three-wire earth resistance measurement for precise readings
Battery-powered for field testing
Meets IEC and VDE safety standards
Includes test leads and earth rods for immediate use
1 x Earth Tester PCE-ET 3000
1 x Test cable set (15 m red, 10 m yellow, 5 m green)
1 x Set of earth rods
Product identification
- Brand: PCE INSTRUMENTS
- Model / MPN: PCE-ET 3000
