PCE Instruments Industrial Platform Scale (PCE-EP 150P1)
PCE Instruments Industrial Platform Scale (PCE-EP 150P1) is a versatile and high-precision scale designed for industrial and warehouse applications. With a dual-range capacity of up to 150 kg, this platform scale ensures accurate weight measurement for various tasks.
This platform scale supports multiple weighing applications, including gross/net weighing, summing, peak hold, and animal weighing. Its filter function for dynamic weighing and container weighing feature make it ideal for industrial use.
Specifications and Dimensions
Measuring Range: Max. 1 = 60 kg / Max. 2 = 150 kg
Resolution: Up to 60 kg = 10 g; 60 kg – 150 kg = 20 g
Measurement Uncertainty: ± 3 d
Platform Size: 400 x 500 mm
Tare Function: Over the entire weighing range
Interface: RS232 Bidirectional / D-SUB 9 Female
Optional Outputs: 4-20 mA analog, 4 potential-free outputs (LO/OK/HI/Stability)
Display: LCD with 25 mm digit height
Units: kg / lb (freely adjustable)
Cable Length: Approx. 160 cm (with attached plug)
Power Supply: 6V / 4.5Ah battery or 9V / 1.2A power adapter (included)
Power Consumption: 70 mA
Protection Class: IP54
Operating Temperature: 0 … +40°C / 10 … 80% RH
Weight: Approx. 14 kg
Key Features and Benefits
Dual-range weighing function for improved accuracy
Bidirectional RS232 interface for data transfer
Removable tripod mount for flexible placement
Battery or mains operation for mobility
1 x Platform Scale PCE-EP 150P1
1 x Display (with battery)
1 x Tripod with bracket
1 x Power adapter
Product identification
- Brand: PCE INSTRUMENTS
- Model / MPN: PCE-EP 150P1
