Victron Orion-Tr Smart 24/12V 20A 240W DC-DC Charger (ORI241224120)
Victron ORI241224120 Orion-Tr Smart 24/12V 20A 240W DC-DC Charger is a high-efficiency isolated DC-DC charger with built-in Bluetooth, designed for dual-battery systems in vehicles and boats. It provides adaptive 3-stage charging for optimal battery performance.
Built-in Bluetooth: Allows wireless monitoring and configuration via the VictronConnect app.
Galvanic Isolation: Ensures electrical separation between input and output for enhanced safety.
Adaptive 3-Stage Charging: Optimizes charging for lead-acid and lithium batteries.
Remote On/Off Control: Enables easy switching without high-current wiring.
Parallel Operation: Multiple units can be connected to increase output power.
Voltage Adjustment: Output voltage can be fine-tuned for specific applications.
High Temperature Tolerance: Delivers full-rated output up to 40°C and operates up to 55°C.
Ensures efficient charging for service batteries in dual-battery systems.
Protects sensitive electronics with stable voltage output.
Supports both 12V and 24V systems for versatile applications.
Provides real-time monitoring and configuration via Bluetooth.
Technical Specifications:
Model: ORI241224120
Input Voltage Range: 16-35V
Output Voltage Range: 10-15V
Continuous Output Current: 20A (at nominal voltage and 40°C)
Maximum Output Current: 50A (for 10s at nominal voltage minus 20%)
Product identification
- Brand: Victron
- Model / MPN: ORI241224120
