PCE Instruments Infrared Digital Thermometer with Type K Input (PCE-675)
PCE Instruments Digital Thermometer (PCE-675) is a versatile temperature measurement tool equipped with both infrared and Type K thermocouple input. Designed for precision, it measures surface temperatures from -50 to 550 °C with infrared technology and up to 850 °C using a Type K sensor. The adjustable emissivity ensures accurate readings on various materials.
This infrared digital thermometer also features air temperature, humidity, wet bulb, and dew point measurement capabilities, making it ideal for HVAC inspections, industrial applications, and environmental monitoring.
Specifications and Dimensions
Infrared Measuring Range: -50 … 550 °C
Type K Measuring Range: -50 … 850 °C
Air Temperature Range: -20 … 60 ºC
Humidity Measurement: 0 … 100 % RH
Dew Point Range: -20 … 60 ºC
Wet Bulb Temperature: -20 … 60 ºC
Resolution: 0.1 °C / 0.1 °F
Emissivity: Adjustable between 0.1 and 1.0
Optical Resolution: 13:1
Laser: ≤ 1 mW, 630 … 670 nm, Class 2
Response Time: ≤ 500 ms
Power Supply: 9V battery
Dimensions: 150 x 25 x 27 mm / 5.9 x 1 x 1.1 in
Weight: Approx. 130 g
Key Features and Benefits
Dual measurement capability with infrared and Type K input
Adjustable emissivity for improved accuracy on different surfaces
Measures air temperature, humidity, wet bulb, and dew point
Laser-guided targeting for precise readings
Large digital display with backlight for easy reading
Portable and lightweight design for field use
Ideal for HVAC inspections, industrial applications, and environmental monitoring
Automatic shutdown to extend battery life
Product identification
- Brand: PCE INSTRUMENTS
- Model / MPN: PCE-675
