Jet L100-150WO-50 1-1/2 Ton 50' Lift w/ Overload Protection (201150)
The Jet L100-150WO-50 1-1/2 Ton 50' Lift w/ Overload Protection (201150) is a robust 1.5-ton (3,000 lbs) capacity hand chain hoist ideal for lifting and lowering heavy objects in industrial settings. With a remarkable 50-foot lifting height, this hoist tackles various overhead material handling tasks.
KEY FEATURES AND BENEFITS
Safety First: Overload protection safeguards against exceeding the hoist's capacity. The patented fused brake system ensures reliable stopping power with minimal maintenance. Double ratchet pawl brakes and 360° rotating hooks enhance load security and rigging ease.
Built to Last: The JET L100 series boasts all-steel construction for superior durability in harsh environments. Grade 100 load chain offers 20% greater strength compared to Grade 80 chains. Heat-treated parts, cast-steel safety latches, and double sealed ball bearings further extend the hoist's lifespan.
Standards Compliance: This JET hoist meets stringent ANSI/ASME B30.16 and HST-2 safety standards, ensuring user confidence.
Capacity: 1.5 tons (3,000 lbs)
Lift Height: 50 feet
Load Chain: Grade 100, corrosive resistant plated
Features: Overload protection, fused brake system, double ratchet pawl brake, 360° rotating hooks, heat-treated load plates
Construction: All-steel
Securely attach the hoist: Securely attach the hoist to a sturdy overhead support structure with a rated capacity exceeding the load weight.
Inspect the hoist: Inspect the hoist for any damage and ensure the chain and hooks are properly lubricated.
Position the load hook: Position the load hook directly beneath the object to be lifted.
Pull the hand chain: Pull the hand chain steadily to raise the load. The hoist operates on a one-hand operation principle.
Lower the load: To lower the load, slowly release the hand chain while maintaining control.
Never exceed the hoist's rated capacity: Never exceed the hoist's rated capacity. Utilize a hoist with a higher capacity if necessary.
BENEFITS OF USING Jet L100-150WO-50 1-1/2 Ton 50' Lift w/ Overload Protection (201150)
Safely and efficiently lift and lower heavy objects in industrial environments.
Extended lifting height of 50 feet tackles diverse material handling tasks.
Durable construction ensures reliable performance in demanding conditions.
Built-in safety features protect users and prevent equipment damage.
Compliance with industry standards guarantees safe operation.
1.5-ton lifting capacity
50-foot lift height
Overload protection
Patented fused brake system
Double ratchet pawl brake
360° rotating hooks with overload indication
Grade 100 load chain
Heat-treated load plates
Cast-steel safety latches
Double sealed ball bearings
All-steel construction
ANSI/ASME B30.16 and HST-2 compliant
Product identification
- Brand: Jet
- Model / MPN: 201150
