Grizzly Industrial 2-Axis Lathe DRO System
Grizzly Industrial 2-Axis Lathe DRO includes highly accurate linear optical scales and an intuitive digital readout designed for seamless lathe operation. With advanced features like pitch circle diameter (PCD) and line hole positioning, this DRO system simplifies complex machining tasks while ensuring consistent results.
The readout is housed in a sealed aluminum case, protecting the circuitry from dust, fumes, and coolant. Each scale is equipped with durable plastic seals for oil resistance and smooth movement, thanks to a P5-grade bearing system.
Specifications and Dimensions
T32999: Scale travel lengths: 5-15/16", 31-1/2", Accuracy: ±6μm
T33000: Scale travel lengths: 5-15/16", 43-5/16", Accuracy: ±6μm, ±15μm
T33001: Scale travel lengths: 7-7/8", 13-13/16", Accuracy: ±6μm
T33008: Scale travel lengths: 7-7/8", 39-3/8", Accuracy: ±6μm, ±10μm
T33009: Scale travel lengths: 7-7/8", 43-5/16", Accuracy: ±6μm, ±15μm
T33012: Scale travel lengths: 9-7/8", 43-5/16", Accuracy: ±6μm, ±15μm
T33017: Scale travel lengths: 13-13/16", 51-3/16", Accuracy: ±6μm, ±25μm
T33018: Scale travel lengths: 13-13/16", 63", Accuracy: ±6μm, ±25μm
Supply voltage: DC 5V
Optical period: 20μm
Optical measurement: Transmissive infrared
Repeatability: 2μm
Seal protection: IP53
Scanning head sliding system: Vertical five-bearing sliding system
Key Features and Benefits
Advanced DRO functions: PCD, inclined machining, and radius calculations
Plastic seals for enhanced oil resistance and durability
Smooth and accurate scale motion supported by P5-grade bearings
Product identification
- Brand: Grizzly Industrial
