FiTech fuel pump details
FiTech 2 Barrel 400HP Classic Gold EFI In-Tank Fuel Pump & CDI (93991)
KEY FEATURES AND BENEFITS:
Converts 2-barrel carbureted engines to electronic fuel injection.
Supports engines up to 400 horsepower, enhancing overall performance.
Self-learning technology simplifies tuning and setup.
Wide-band O2 sensor for accurate fuel mixture monitoring.
Complete kit includes all necessary components for installation.
Fuel Injection Style: Throttle body
Fuel Injection System Type: Single 2-Barrel Throttle Body (2300 Flange)
Maximum Horsepower with Gas: 400 HP
Timing Control Compatible: Yes
ECM Included: Yes
Self Tuning: Yes
User Tunable: Yes
Ignition System Included: Ignition box
User Interface Included: 4.5 in. display
Throttle Body Mounting Flange: 4-barrel square bore
Venturi Quantity: 4
Venturi Diameter (mm): 44.00mm
Airflow Rate (cfm): 500 cfm
Injector Size: 62 lbs./hr.
Preparation: Disconnect the battery and remove the existing carburetor and fuel system components.
Fuel System Installation: Install the in-tank fuel pump module, ensuring proper connections and secure mounting.
Throttle Body Installation: Mount the 2-barrel throttle body onto the intake manifold, using the provided gasket.
Sensor Installation: Install the wide-band O2 sensor, coolant sensor, MAP sensor, IAT sensor, and TPS sensor, connecting them to the wiring harness.
Wiring Connections: Connect the wiring harness to the ignition system, fuel pump, and power source, following the provided instructions.
Go-Spark CDI Installation: Install the Go-Spark CDI ignition system and connect it to the distributor and wiring harness.
Handheld Controller Connection: Connect the handheld controller to the ECU for initial setup and tuning.
Initial Setup: Use the handheld controller to input engine parameters and perform the initial setup.
Start and Tuning: Start the engine and allow the self-learning system to adjust fuel parameters. Fine-tune as needed using the handheld controller.
BENEFITS OF USING THE FITECH 2 BARREL 400HP CLASSIC GOLD EFI IN-TANK FUEL PUMP & CDI (93991):
Improved engine performance and throttle response.
Enhanced fuel economy.
Easier engine starting and improved idle quality.
Simplified tuning with self-learning technology.
Integrated ECU within the throttle body.
In-tank fuel pump module included.
Handheld controller for setup and tuning.
Compatible with various distributor types.
Utilizes a speed density metering style.
44mm venturi size.
62 lbs./hr. injectors.
Product identification
- Brand: FiTech
- Model / MPN: 93991
