Zeeline 10" X 5" Air Sentry (ZED-108)
D-Series Air Sentry Breathers: The D-Series breathers feature numerous models in a variety of sizes, designed to satisfy the requirements of most stationary fluid management applications. The breathers provide application flexibility by using 100% silica gel for moisture adsorption or 100% activated carbon for fume and odor control, or both when necessary. All D-Series models feature 2-micron solid particle filtration and have a max airflow rating of 20 cfm. They also have a max reservoir fluid flow rate of 150 GPM. The D-Series is constructed of industrial grade raw materials, tested to ensure a wide range of chemical compatibilities, and features high impact resistant ABS top and bottom caps.
Ideal solution for fluid contamination problems
Blocks corrosive water vapor
Filters damaging particles
Reduces other contaminates
Protects expensive equipment
Disposable- replace when desiccant color changes from gold to green
Typical Applications: storage tanks, fluid reservoirs, transformers, pumps, and gearboxes.
Mounting Connection: 2" NPT (M)
Max Adsorption Capacity: 21.47 fl oz.
Product identification
- Brand: ZeeLine
- Model / MPN: ZED-108
