Yuken Solenoid Operated Dir 3-Pos 4-Way 120 VAC JIS (DSG-03-3C5-A120-50)
Yuken Solenoid Operated Dir 3-Pos 4-Way 120 VAC JIS (DSG-03-3C5-A120-50) is a highly efficient and reliable solenoid directional valve designed to provide precise flow control in hydraulic systems. With a 3-position and 4-way configuration, it offers flexibility for a range of applications.
This 4-way directional valve 120 VAC operates at a maximum pressure of 31.5MPa (4,570psi) and supports a maximum flow rate of 120L/min (31.7gal/min), making it suitable for heavy-duty industrial uses. It includes a manual override pin, allowing for manual operation when needed, ensuring operational safety and reliability.
Specifications and Dimensions
US Customs Harmonized Code: 8481.20.0020
Country of Origin: Japan
CETOP D05 solenoid directional valve – standard
Max. Pressure: 31.5MPa (4,570psi)
Max. Flow: 120L/min (31.7gal/min)
Key Features and Benefits
High operating pressure of 31.5MPa for enhanced hydraulic performance.
High flow rate of up to 120L/min ensures efficient fluid control in large systems.
3-position, 4-way configuration for versatile flow control.
Includes a manual override pin for additional operational safety.
Durable design manufactured in Japan, ensuring long-term reliability.
Product identification
- Brand: Yuken
- Model / MPN: DSG-03-3C5-A120-50
