Yuken Directional Valve Solenoid Operated (DSG-03-2D2-A240-50)
Yuken Directional Valve Solenoid Operated (DSG-03-2D2-A240-50) is designed for high-pressure hydraulic systems, providing consistent performance and precise flow control. This model operates with a maximum pressure of 31.5 MPa (4,570 PSI) and can handle a flow rate of up to 120 L/min.
The Yuken solenoid directional valve features a 240V AC coil for efficient power management and is built to CETOP D05 standards. With a robust structure and Japanese engineering, it is suitable for heavy-duty use in various hydraulic systems.
Specifications and Dimensions
US Customs Harmonized Code: 8481.20.0020
Country of Origin: Japan
Maximum Operating Pressure: 31.5 MPa (4,570 PSI)
Maximum Flow Rate: 120 L/min (31.7 U.S. GPM)
Model Type: CETOP D05 Solenoid Directional Valve – Standard
Key Features and Benefits
Handles high pressure up to 31.5 MPa for heavy-duty hydraulic applications
240V AC coil for energy-efficient operation
Manual override pin for added control flexibility
Meets CETOP D05 standards for compatibility with a wide range of systems
Manufactured in Japan for top-tier quality and durability
Product identification
- Brand: Yuken
- Model / MPN: DSG-03-2D2-A240-50
