Wera 160i VDE Slotted Driver 1.6 x 10mm
Wera 05006140001 is a VDE 160i Kraftform Plus insulated slotted screwdriver with a 1.6 x 10mm tip and nominal 200mm blade. The description distinguishes a 1000V rating from testing at 10,000V. The wider slotted tip requires matching both slot width and thickness; insulation and blade reach are separate selection checks.
Specifications and included details
- Slotted tip 1.6 x 10mm; nominal blade length 200mm.
- Listed 1000V rating and 10,000V test voltage.
- Multi-component Kraftform handle with anti-roll feature.
Before ordering
The test voltage is not an operating rating. Follow manufacturer inspection requirements and the applicable electrical work procedure. Use the labeled metric blade length rather than treating the rounded 8-inch designation as an exact conversion.
Product questions and answers
Can the screwdriver be used at 10,000V?
No. That is the stated test voltage; the stated rating is 1000V.
Does 10mm describe the blade thickness?
No. The stated tip is 1.6mm thick and 10mm wide.
Is 200mm the total tool length?
No. It identifies the nominal blade length.
