Wera 05006170001 TX10 167i VDE Screwdriver
Wera 167i VDE screwdriver 05006170001 has a TX10 Torx working tip, an 80mm blade and a listed 161mm overall length. The details describe individual IEC 60900 testing and insulation for work up to 1,000V. Its Kraftform Plus handle combines hard and soft zones with an anti-roll shape.
Specifications and included details
- TX10 Torx tip with 80mm blade; overall length 161mm.
- VDE insulated format; IEC 60900 individual testing described.
- Listed 1,000V insulation application and Kraftform Plus handle.
Before ordering
Verify actual tool markings and insulation condition, and follow electrical safe-working procedures. Insulation does not remove arc-flash hazards or authorize live work. Match TX10 to the recess; this is not an external E10 Torx wrench.
Product questions and answers
Is 80mm the complete tool length?
No. It is the listed blade length; overall length is 161mm.
Is TX10 the same as an E10 opening?
No. TX10 is an internal Torx driver tip; E10 identifies an external Torx tool opening.
Does VDE insulation mean ESD protection?
No. Electrical insulation and electrostatic-discharge control are different requirements; an ESD rating is not supplied.
