Viair 250C IG 25058 24V Compressor Kit
The Viair 250C IG 25058 is the 24V option in the industrial-grade compressor family. Its leader hose and check-valve arrangement support an installed air-system setup, which still needs an appropriate tank, controls and electrical installation rather than being treated as a complete portable inflator.
Specifications and included details
- 24V model; listed maximum 24V current draw 6 A.
- 150 PSI maximum working pressure and 100% duty cycle at 100 PSI.
- Listed maximum air-tank size 2.5 gallons; tank inclusion is not established.
- PTFE-lined stainless-steel braided leader hose, check valve, thermal overload protection and two replacement filter elements.
Before ordering
Order for the correct 24V system; the family specifications also mention a separate 12V version. Confirm pressure controls, tank suitability, wiring and mounting instructions. A 100% duty cycle at 100 PSI does not establish continuous operation at 150 PSI.
Product questions and answers
Does the family reference to 12V/24V mean this unit accepts both?
Do not assume dual-voltage operation. The 25058 listing identifies the 24V option, with a separate 6 A maximum-current specification. Match the actual unit to the electrical system.
Is a 2.5-gallon tank included?
The figure is a maximum tank-size specification, not an included tank. The stated kit components do not establish tank inclusion.
Can it run continuously at 150 PSI?
The stated 100% duty cycle applies at 100 PSI. The separate 150 PSI maximum pressure does not establish the same duty cycle at that pressure.
