Phoenix USA Polished Alcoa Aluminum Wheel (763297)
The Phoenix USA Polished Alcoa Aluminum Wheel (763297) is a premium-grade forged aluminum wheel engineered for heavy-duty truck applications. This wheel is specifically designed as a direct fit for Ford F450 and F550 Super Duty models (from 2005 to the current year) and RAM (Dodge) 4500 and 5500 models (from 2008 to the current year). Its polished finish on both sides not only provides a visually appealing upgrade but also contributes to the wheel's resistance to environmental factors. Constructed from robust Magna Force forged aluminum, this wheel offers an optimal balance of strength and weight, contributing to improved handling and fuel efficiency compared to heavier steel alternatives.
KEY FEATURES AND BENEFITS:
Wheel Size: 19.5 x 6 inches specifically tailored for compatible vehicles, ensuring proper tire fitment and load-bearing capacity.
Material Composition: Constructed from durable Magna Force forged aluminum, providing resistance to corrosion, vibration, and wear.
Secure Fit: The 10 x 225mm bolt pattern and hub pilot dual-mounting system guarantee a secure and precise fitment.
High-Polished Finish: Enhances the truck's appearance and protects against corrosion and wear, maintaining aesthetic appeal over time.
Exceptional Strength: Supports a maximum load capacity of 4000 lbs at 115 psi, ensuring reliable performance under demanding conditions.
Effective Heat Dissipation: Ten hand/vent holes aid in cooling brakes and tires, potentially extending their lifespan and improving safety.
Direct Replacement: Serves as a direct replacement for Alcoa part numbers 763200 and 763207, simplifying the upgrade process.
Material: Magna Force Forged Aluminum (6061)
Finish: Polished Both Sides (Mirror Polish)
Bolt Pattern: 10 x 225mm
Mounting System: Hub Pilot, Dual-Mounting
Hub Bore Diameter: 170.2mm
Bolt Hole Diameter: 15mm
Outset: 5.35 inches
Inset: 4.82 inches
Approximate Weight: 26 – 33 lbs (variable by source)
Maximum Load Capacity: 4000 lbs @ 115 psi
Maximum Cold Inflation: 130 psi
Valve Stem: TR553C (Pre-installed)
Disc Thickness: 0.53 inches
Hand/Vent Holes: 10 @ 2 inches
Recommended Tire Sizes: 225/70R19.5 (Optimal), 245/70R19.5, 8R19.5
Preparation: Ensure the vehicle is safely parked on a level surface with the parking brake engaged. Gather necessary tools, including a lug wrench, torque wrench, and potentially a jack and jack stands if replacing an existing wheel.
Removal (if replacing): Loosen the lug nuts of the wheel you intend to replace without removing them completely.
Lifting the Vehicle (if replacing): Carefully lift the vehicle using the jack until the tire is off the ground, securing it with jack stands for added safety.
Removing the Old Wheel (if replacing): Fully unscrew the lug nuts and carefully remove the old wheel from the hub.
Mounting the Alcoa Wheel: Align the bolt holes of the Alcoa aluminum wheel with the studs on the vehicle's hub and carefully mount the wheel onto the hub.
Securing the Wheel: Hand-tighten the lug nuts in a star pattern to ensure even pressure.
Lowering the Vehicle (if lifted): Carefully lower the vehicle until the wheel is just touching the ground.
Final Tightening: Use a torque wrench to tighten the lug nuts to the manufacturer's recommended specifications in a star pattern.
Final Check: Double-check the torque of the lug nuts after a short period of driving.
BENEFITS OF USING THE PHOENIX USA POLISHED ALCOA ALUMINUM WHEEL (763297):
Enhanced Aesthetics: The high-polished finish significantly improves the overall appearance of the vehicle, adding professionalism and pride.
Weight Reduction: Compared to steel wheels, the aluminum construction contributes to improved fuel efficiency and better handling and braking performance.
Superior Strength: Ensures reliability and safety under heavy loads and demanding driving conditions.
Improved Heat Dissipation: Vent holes help prolong the life of tires and brake components.
Corrosion Resistance: The polished finish helps maintain the wheel's appearance and structural integrity over time, reducing maintenance needs.
Constructed from 6061 Magna Force forged aluminum: Offers exceptional strength-to-weight ratio.
High-Luster Polish: Provides a premium look and added protection on both surfaces.
Precise 10 x 225mm Bolt Circle: Ensures secure and accurate mounting.
Hub-Centric Mounting System: Ensures perfect alignment with the vehicle's hub.
Ventilation Holes: Ten strategically placed holes facilitate brake and tire cooling.
Optimized Wheel Positioning: Designed with an outset of 5.35 inches to enhance stability.
Pre-Installed Valve Stem: Convenient TR553C valve stem included.
Maximum Load Capacity: Supports up to 4000 lbs for demanding tasks.
Product identification
- Brand: Phoenix USA
- Model / MPN: 763297
