Stud extender details
Phoenix USA NF14 Stud Extender (PNF14STX)
The Phoenix USA NF14 Stud Extender (PNF14STX) is a crucial component designed specifically for use with Phoenix USA's NF14 wheel simulator kits. This stud extender provides the necessary additional length to your vehicle's existing wheel studs, ensuring a secure and proper mounting of the wheel simulators. Engineered with precision and manufactured to meet stringent quality standards, the PNF14STX guarantees reliable performance and a correct fit for its intended application. This essential part facilitates the seamless installation of NF14 simulator kits, enhancing the appearance of your vehicle while maintaining wheel safety and integrity.
KEY FEATURES AND BENEFITS:
Precise Fitment: Specifically designed for the NF14 simulator kit, ensuring compatibility with designated vehicles.
Required Length: Provides the extra length needed for secure mounting of wheel simulators, preventing issues with insufficient stud protrusion.
Durable Construction: Likely manufactured from robust materials (potentially steel or brass) to withstand the stresses of wheel mounting and regular use.
Correct Threading: Features an M14x1.5 internal thread, precisely matching the wheel studs of compatible vehicles for a secure connection.
Facilitates Simulator Installation: Enables the straightforward and correct installation of Phoenix USA NF14 wheel simulators.
Product Name: Stud Extender
Part Number: PNF14STX
Inner Diameter (ID): M14 x 1.5mm
Outer Diameter (OD): 7/8" (approximately 22.225 mm)
Height/Tall: 0.94" (approximately 23.876 mm)
Length: 0.88" (approximately 22.352 mm)
Weight: 0.1100 lbs (approximately 50 grams)
Compatibility: Specifically for use with Phoenix USA NF14 simulator kits on 2014-Current Ford Transit Van 2WD only with 16" diameter by 6" wide, dual-rear-wheel, 12 hand hole, 6 lug on 180mm bolt circle, M14x1.5 lug stud applications.
Material: Likely Steel (based on typical automotive stud components)
Finish: Not explicitly stated, but may have a protective coating like zinc plating.
Preparation: Ensure the vehicle is safely parked on a level surface with the parking brake engaged. Loosen, but do not remove, the lug nuts on the wheel where the simulator will be installed.
Wheel Removal (If Necessary): If the existing studs are not sufficiently exposed, carefully remove the wheel.
Stud Extender Installation: Thread the Phoenix USA PNF14STX stud extender onto the existing wheel stud. Ensure it is threaded on completely and is snug. Do not overtighten at this stage.
Repeat for All Studs: Repeat step 3 for all the wheel studs on the hub where the NF14 simulator will be mounted.
Simulator Placement: Carefully position the NF14 wheel simulator over the extended studs, aligning the holes in the simulator with the stud extenders.
Secure with Jam Nuts (Not Included): Secure the wheel simulator using the appropriate jam nuts (these are typically included with the NF14 simulator kit, not the stud extender itself). Tighten the jam nuts evenly and to the manufacturer's recommended torque specifications.
Wheel Reinstallation (If Removed): If the wheel was removed, carefully reinstall it, aligning the lug holes with the studs (now extended with the PNF14STX).
Lug Nut Tightening: Tighten the lug nuts in a star pattern to the manufacturer's recommended torque specifications.
Final Check: After lowering the vehicle, double-check the tightness of all lug nuts and jam nuts.
BENEFITS OF USING PHOENIX USA NF14 STUD EXTENDER (PNF14STX):
Ensures proper simulator fitment by providing the necessary stud length for the secure attachment of Phoenix USA NF14 wheel simulators.
Helps maintain the safety and integrity of the wheel mounting system by enabling correct installation.
Simplifies the installation process of NF14 wheel simulators, reducing time and effort.
Guarantees perfect compatibility with the NF14 kit and intended vehicle applications.
Delivers reliable performance thanks to quality materials and precision engineering by Phoenix USA.
M14 x 1.5 Internal Thread: Designed to precisely match the thread pitch of compatible Ford Transit van wheel studs.
7/8" Outer Diameter: Provides a stable base for securing the wheel simulator.
0.94" Overall Height: Offers the specific extension length required for the NF14 simulator mounting.
Hexagonal Base (Implied): Likely features a hexagonal base (similar to other Phoenix USA stud extenders) for easy installation and tightening using a standard wrench.
Product identification
- Brand: Phoenix USA
- Model / MPN: PNF14STX
