Phoenix USA DOT Sim Set ND1912 w/ Air Max AML2 (ND1912M)
The Phoenix USA DOT Sim Set ND1912 w/ Air Max AML2 (ND1912M) offers a comprehensive solution for enhancing the aesthetics and simplifying the maintenance of your Dodge RAM 4500 or 5500 series truck. Specifically designed for models from 2008 to the current year that are equipped with 19.5-inch diameter wheels featuring a 10-lug bolt pattern and 5 hand holes, this kit provides a significant visual upgrade and added convenience. The set includes four high-quality, polished stainless steel wheel simulators – two for the front wheels and two for the rear dual wheels – along with the innovative Air Max AML2 air inflation kit for the rear tires. This combination not only gives your truck a more refined and finished appearance, akin to having custom alloy wheels, but also makes the often cumbersome task of checking and inflating the inner and outer rear tires much easier.
KEY FEATURES AND BENEFITS:
Enhanced Appearance: Polished stainless steel construction ensures long-lasting resistance against rust and corrosion, maintaining a bright and attractive look.
Simple Installation: The DOT-compliant, over-the-lug mounting system allows for a secure fit directly over your existing lug nuts without the need for their removal.
Broad Compatibility: Hardware included is compatible with both 9/16" (for 2007-2011 models) and M14x1.5 (for 2012-present models) lug studs.
Thoughtful Design: Front simulators feature a dish shape, while rear simulators have a deeper dish to complement the dual-wheel setup.
Air Max AML2 Kit: The integrated kit improves accessibility of the rear tire valve stems, eliminating the need to remove wheel simulators for tire inflation.
Product Name: Phoenix USA DOT Sim Set w/ Air Max AML2
Product Part Number: ND1912M
Vehicle Fitment: Dodge RAM 4500 / 5500 (2008 – Current)
Wheel Diameter Compatibility: 19.5 inches
Lug Nut Count: 10
Hand Hole Count: 5
Wheel Simulator Material: Polished Stainless Steel
Mounting Style: DOT Over-the-Lug, Bolt-On, Stud/Bracket Mount
Front Simulator Design: Dish Shape
Rear Simulator Design: Deep Dish
Rear Tire Inflation Kit: Air Max AML2
Air Max Extension Material: Braided Stainless Steel
Air Max Extension Quantity: 4 (2 Inner, 2 Outer with 117-degree bend on outer)
Lug Stud Compatibility: 9/16" and M14x1.5
Lug Nut Compatibility (Air Max): 5/8"
Included Hardware: Mounting brackets, lug nut covers, installation tool, instruction sheet.
Preparation: Ensure your vehicle is parked on a level surface with the parking brake engaged. Gather all components of the Phoenix USA DOT Sim Set ND1912M and the provided installation tool.
Front Simulator Installation: Position the front wheel simulator against the wheel, aligning the holes in the simulator with the lug nuts on your wheel.
Secure Front Simulator: Using the provided hardware (typically lug nut covers with integrated fasteners), thread them onto your existing lug nuts, tightening them evenly until the front simulator is securely attached to the wheel.
Rear Simulator Installation (Outer): Position the outer rear wheel simulator against the outer rear wheel, aligning the holes with the lug nuts.
Secure Outer Rear Simulator: Similar to the front, use the provided hardware to thread onto the lug nuts, tightening evenly to secure the outer rear simulator.
Air Max Extension Installation (Inner Rear): Locate the valve stem on the inner rear wheel. Attach one of the straight braided stainless steel extensions to this valve stem, ensuring a tight and secure connection. Route the extension outwards through one of the hand holes in the outer wheel. Secure the mounting bracket for this extension to one of the lug studs using the provided hardware.
Air Max Extension Installation (Outer Rear): Locate the valve stem on the outer rear wheel. Attach one of the 117-degree bent braided stainless steel extensions to this valve stem. Secure the mounting bracket for this extension to one of the lug studs using the provided hardware.
Repeat for Other Side: Follow steps 4 through 7 for the other set of rear dual wheels.
Final Check: Once all simulators and valve extensions are installed, double-check that all mounting hardware is secure and that the valve stem extensions are easily accessible for tire inflation.
BENEFITS OF USING THE PHOENIX USA DOT SIM SET ND1912 W/ AIR MAX AML2 (ND1912M):
Provides a significant enhancement to the vehicle's appearance, transforming the look of standard steel wheels to resemble high-end alloy wheels.
Durable stainless steel construction ensures longevity and resistance to the elements, maintaining its polished finish despite harsh road conditions.
Simplified installation process allows for achieving this upgrade without the need for professional assistance or specialized tools.
Increased convenience in tire maintenance offered by the Air Max AML2 kit, eliminating the need to remove the wheel simulators to access the valve stems of the inner rear tires.
Saves time and effort while encouraging regular tire maintenance, which can lead to improved fuel efficiency and enhanced safety.
Constructed from premium polished stainless steel for a lasting, brilliant shine.
Designed specifically for 19.5-inch, 10-lug, 5 hand hole dual-rear-wheel setups on Dodge RAM 4500/5500 (2008-Present).
Front simulators feature a contoured dish design.
Rear simulators boast a deep dish profile to complement the dual wheel configuration.
DOT-compliant over-the-lug mounting for secure and straightforward attachment.
Includes hardware adaptable for both 9/16" and M14x1.5 lug stud sizes.
Braided stainless steel valve stem extensions for the inner and outer rear wheels.
Outer rear valve extensions feature a 117-degree bend for optimal accessibility.
Secure mounting brackets for the valve stem extensions utilizing existing lug studs.
Protective rolled edges on the simulators for added strength and handling safety.
Product identification
- Brand: Phoenix USA
- Model / MPN: ND1912M
