PCE Instruments Soil pH and Temperature Meter (PCE-228S)
PCE Instruments Soil pH and Temperature Meter (PCE-228S) is a professional measuring device for determining pH levels and temperature in soil and agricultural substrates. Designed for gardeners, agronomists, and environmental professionals, it provides precise measurements to ensure optimal growing conditions for crops, plants, and greenhouse cultivation.
It features a specialized soil pH electrode for direct measurement in loosened soil. It offers manual or automatic temperature compensation for accurate readings. This meter is ideal for soil testing in horticulture, hydroponics, and precision agriculture.
Specifications and Dimensions
pH Measurement Range: 0.00 … 14.00 pH
Redox Measurement Range: -1999 … 0 … 1999 mV (with optional Redox electrode)
Temperature Range: 0.0 … 65.0°C / 32 … 149°F (with temperature sensor)
Resolution: 0.01 pH, 1 mV, 0.1°C
Accuracy: ±(0.02 pH + 2 digits), ±(0.5% + 2 digits), ±0.5°C
Temperature Compensation: Automatic (0 – 65°C) or manual (0 – 100°C)
Electrode: PCE-PH-ES soil pH electrode with BNC connection
Memory: SD card (1 – 16 GB, 2 GB included)
Power Supply: 6 x 1.5V AA batteries or optional 9V adapter
Operating Temperature: 0 … 50°C / 32 … 122°F
Dimensions: 177 x 68 x 45 mm / 7 x 2.7 x 1.8 in
Weight: 490 g / 1.1 lb
Key Features and Benefits
Accurate pH measurement for soil, substrates, and irrigation solutions
Includes specialized soil pH electrode for direct ground penetration
Automatic temperature compensation for consistent readings
Stores data on an SD card in Excel format for easy documentation
1 x PCE-228S Soil pH Meter
1 x PCE-PH-ES Soil pH Electrode
1 x SD Memory Card (2 GB)
1 x Temperature Sensor
6 x AA Batteries
Product identification
- Brand: PCE INSTRUMENTS
- Model / MPN: PCE-228S
