PCE Instruments Heat Pump Test Equipment with Ethernet and PoE
PCE Instruments Heat Pump Test Equipment is designed for accurate flow measurement in copper pipes using ultrasonic transit time technology. Its non-invasive clamp-on sensor allows for easy installation without interrupting operations, making it ideal for HVAC systems, industrial applications, and heat pump performance monitoring.
It supports Ethernet communication and Power over Ethernet (PoE), allowing seamless data transmission and cloud storage. This makes remote access and analysis of measurement data convenient for system optimization and efficiency improvements.
Specifications and Dimensions
Flow Velocity Range: 0.03 to 5 m/s
Resolution: 0.01 m/s
Accuracy: ±2% of Rd (0.3 to 5 m/s)
Volume Flow Measurement Range: 0.04 to 6 m³/h
Resolution: 0.01 m³/h
Display Type: LC color display
Display Size: 1.44 inches
Display Resolution: 128 x 128
Interface: Ethernet, PoE
Pipe Material Compatibility: Copper
Measured Medium: Water
Repeatability: 0.2%
Communication Protocols: HTTP, MQTT
Menu Languages: English, Chinese
Protection Class: IP54
Power Supply: PoE (Power over Ethernet)
Connector Type: RJ45
Operating Conditions: -10 to 50°C, 0 to 99% RH
Storage Conditions: -10 to 50°C, 0 to 99% RH
Device Dimensions (L x W x D): 65 x 111 x 43 mm
Key Features and Benefits
Non-invasive ultrasonic measurement for copper pipes
Clamp-on sensor eliminates the need to cut pipes
Rotatable LCD display for flexible mounting positions
Power over Ethernet (PoE) for simplified installation
Real-time monitoring of flow velocity and volume
Remote data access and cloud storage via Ethernet
Ideal for heat pump testing, HVAC systems, and industrial processes
1 x Heat Pump Test Equipment
1 x Sensor with 9m Ethernet Cable
1 x PoE Network Cable (2m)
1 x Ultrasonic Contact Gel
1 x Silicone Seal (1m)
4 x Coupling Pads
Product identification
- Brand: PCE INSTRUMENTS
