PCE Instruments Digital Pressure Gauge with Multiple Units (PCE-P50)
PCE Instruments Pressure Gauge (PCE-P50) is a highly precise device designed for measuring differential, overpressure, and vacuum pressure in industrial applications. The device features a digital display, min/max memory, and multiple pressure unit selections, making it ideal for technicians and engineers requiring accurate readings.
This pressure gauge is suitable for pneumatic systems, HVAC applications, and laboratory testing. It includes a data hold function, backlit LCD screen, and durable ABS housing for rugged environments. With an optional RS-232 interface, users can transfer measurement data to a PC for real-time analysis.
Specifications and Dimensions
Max. Pressure (positive/negative): 150 psi
PSI Range: 0…±100 / Resolution: 0.1
mbar Range: 0…±6900 / Resolution: 4
inH₂O Range: 0…±2750 / Resolution: 2
inHg Range: 0…±200 / Resolution: 0.1
mmHg Range: 0…±5200 / Resolution: 3
kPa Range: 0…±690 / Resolution: 0.4
cmH₂O Range: 0…±7000 / Resolution: 4
Kg/cm² Range: 0…±7 / Resolution: 0.004
Data Format: 2400 baud, 1 stop bit, 8 data bits
Accuracy: ±0.3 % (full range, @ +25°C / +77°F)
Repeatability: ±0.2 % (max. ±0.5 % of full scale)
Response Time: 0.3 ms
Operating Temperature: max. +50°C / +122°F
Power Supply: 9V DC or optional power adapter
Battery: 1 x 9V block battery PP3
Dimensions: 182 x 72 x 30 mm / 7.1 x 2.8 x 1.1"
Weight: 150 g / 5.3 oz
Key Features and Benefits
Measures overpressure, underpressure, and differential pressure
9 selectable pressure units for easy conversions
Min/max memory and data hold function for reference
Backlit LCD display for clear readings in all lighting conditions
Durable ABS housing for industrial use
Auto power-off function to extend battery life
Compatible with RS-232 interface for data transfer and analysis
1 x Pressure Gauge PCE-P50
1 x Carrying case
1 x PVC hose (1 m / 39")
1 x Instruction manual
Product identification
- Brand: PCE INSTRUMENTS
- Model / MPN: PCE-P50
