PCE Instruments Digital Force Gage/Penetrometer (PCE-PTR 200N)
PCE Instruments Digital Force Gage/Penetrometer (PCE-PTR 200N) is a compact and highly accurate measuring device designed for precise force testing. It supports both tension and compression force measurements, making it ideal for various applications, including quality control, material testing, and laboratory experiments.
The device features a range of measurement adapters to accommodate different testing requirements. It includes a USB interface for data transfer, an integrated load cell with M6 connection, and compatibility with test stands for controlled measurements.
Specifications and Dimensions
Measuring Range: 0 … 200 N / 0 … 45 lbs
Resolution: 0.1 N / 0.02 lbs
Pressure Calibration: 1 MPa
Load Cell: Integrated with M6 connection
Measurement Accuracy: ± 0.5%
Units: N, kg, lb
Operating Temperature: 10 … 30°C / 50 … 86°F
Relative Humidity: 15 … 80% RH
Weight: 1 kg / 2.2 lbs
Key Features and Benefits
Designed for tension and compression force measurements
Peak measurement capability for capturing maximum force values
Supports multiple measurement units: N, kg, lb
Downloadable evaluation software for data analysis
USB interface for easy data transfer
Compatible with test stands for improved repeatability
Includes multiple adapters for various measurement needs
Product identification
- Brand: PCE INSTRUMENTS
- Model / MPN: PCE-PTR 200N
