PCE Instruments Digital Differential Pressure Manometer (PCE-P30)
PCE Instruments Differential Pressure Manometer (PCE-P30) is a highly accurate and versatile device designed for measuring overpressure, underpressure, and differential pressure in various industrial applications. The device features a digital display, min/max memory, and selectable pressure units, making it ideal for professionals who require precise pressure measurements.
This differential pressure manometer is suitable for pneumatic systems, HVAC applications, and laboratory use. With an optional RS-232 interface, measurement data can be transferred directly to a PC for real-time monitoring and analysis.
Specifications and Dimensions
Max. Pressure (positive/negative): 60 psi
PSI Range: 0…±30 / Resolution: 0.02
mbar Range: 0…±2000 / Resolution: 2
inH₂O Range: 0…±830 / Resolution: 0.5
inHg Range: 0…±61 / Resolution: 0.01
mmHg Range: 0…±1500 / Resolution: 1
kPa Range: 0…±200 / Resolution: 0.2
cmH₂O Range: 0…±2100 / Resolution: 2
Kg/cm² Range: 0…±2.1 / Resolution: 0.002
Data Format: 2400 baud, 1 stop bit, 8 data bits
Accuracy: ±0.3 % (full range, @ +25°C / +77°F)
Repeatability: ±0.2 % (max. ±0.5 % of full scale)
Response Time: 0.3 ms
Operating Temperature: max. +50°C / +122°F
Battery: 1 x 9V block battery PP3
Dimensions: 182 x 72 x 30 mm / 7.1 x 2.8 x 1.1"
Weight: 150 g / 5.3 oz
Key Features and Benefits
Measures overpressure, underpressure, and differential pressure
9 selectable pressure units for convenient conversions
Min/max memory and data hold function for easy reference
Backlit LCD display for clear readings in all lighting conditions
Impact-resistant ABS housing for durability in industrial settings
Auto power-off function to conserve battery life
Compatible with RS-232 interface for data transfer and analysis
1 x Differential Pressure Manometer PCE-P30
1 x Carrying case
1 x PVC hose (1 m / 39")
1 x Instruction manual
1 x Protective cover
Product identification
- Brand: PCE INSTRUMENTS
- Model / MPN: PCE-P30
