Mayhew 1.5mm Pin Width Metric Pin Punch (21240)
The Mayhew 1.5mm Pin Width Metric Pin Punch (21240) is a specialized hand tool designed for the precise and safe removal of metric pins and keys. This punch is an essential component for any toolkit requiring careful disassembly, particularly after initial movement of a pin has been achieved. Its purpose is to drive out pins that are no longer seized, ensuring a clean and effective removal process without damaging the surrounding material or the pin itself. Manufactured with attention to detail in the USA, this tool exemplifies quality and reliability, featuring a black oxide finish for enhanced protection against corrosion and rust. Whether you are working on mechanical assemblies, small engines, or other applications requiring the removal of specific metric pins, the Mayhew 21240 offers the precision and performance you need.
KEY FEATURES AND BENEFITS:
1.5mm Pin Width: Tailored for small metric pins, providing a precise fit to ensure accurate force application and minimize slippage.
Designed for Loosened Pins: Specifically made to drive out pins and keys that have already been moved, preventing damage to the punch when used correctly.
Corrosion Protection: Features a black oxide finish that offers resistance against rust and environmental wear, extending the tool's service life.
American Craftsmanship: Proudly made in the USA, indicating adherence to manufacturing standards and quality control.
Lifetime Coverage: Supported by a lifetime assurance, providing confidence in its long-term performance and reliability.
Brand: Mayhew Tools
Length: 4 inches
Width: 0.283 inches
Height: 0.25 inches
Weight: 0.05 lbs
Pin Width: 1.5mm
Pin Length: 3/4 inch
Body Size: 1/4 inch
Finish Type: Black Oxide Finish
Included in Product: One (1) Mayhew 1.5mm Pin Width Metric Pin Punch (21240)
Assess the Pin: Ensure the pin or key you intend to remove is not seized. If it is, proceed to the next step.
Loosen Seized Pins (If necessary): For pins that are stuck or seized, first use a solid punch to initiate movement and loosen the pin. The Mayhew 21240 is not for this initial loosening.
Position the Punch: Once the pin is loosened and has some initial movement, place the 1.5mm pin width of the Mayhew 21240 punch precisely onto the center of the pin.
Strike the Punch: Using a hammer, strike the top of the punch with controlled force. Apply steady, repeated blows to gradually drive the pin out.
Remove the Pin: Continue striking until the pin is fully pushed through the component or sufficiently exposed for removal by hand or pliers.
BENEFITS OF USING MAYHEW 1.5MM PIN WIDTH METRIC PIN PUNCH (21240):
Damage Prevention: The precise 1.5mm tip allows for accurate contact with small metric pins, reducing the likelihood of damaging surrounding material.
Efficient Removal: Streamlines the final stage of pin removal, making the task quicker and less cumbersome.
Reliable Performance: Constructed from hardened steel, ensuring it withstands repeated use without bending or breaking.
Corrosion Resistance: The black oxide coating actively resists rust, maintaining the tool's integrity and appearance.
Optimized for metric pin applications.
Hexagonal body design for a secure grip.
Specifically engineered for the final stage of pin extraction.
Resistant to surface degradation due to its protective coating.
Conforms to manufacturing standards from the USA.
Product identification
- Brand: Mayhew Tools
- Model / MPN: 21240
