Marson Aluminum Klik Thread-Setter Kit w/Inserts & M39300 Tool (39313) (Model M39313)
The Marson Aluminum Klik Thread-Setter Kit w/Inserts & M39300 Tool (39313) is a complete manual fastening system designed to create permanent, load-bearing threads in materials that are too thin for conventional tapping. Suitable for thin-gauge metal, fiberglass, and rigid plastic, the kit installs threaded inserts from one accessible side of the workpiece. It includes the M39300 hand-operated setting tool, interchangeable mandrels and nosepieces, 62 aluminum Klik Thread-Serts, an operator wrench, and a molded storage case. The installed inserts provide secure, reusable attachment points for automotive repair, fabrication, maintenance, and general assembly applications.
Key Features and Benefits:
Broad Thread Compatibility: Supports common imperial thread sizes ranging from #6-32 to 3/8-16.
Single-Sided Installation: Creates threaded mounting points in enclosed structures and panels where rear access is unavailable.
Aluminum Insert Assortment: Includes 62 lightweight threaded inserts suitable for compatible non-corrosive fastening applications.
Mechanical Leverage: The M39300 tool reduces the physical effort required to compress and secure compatible inserts.
Vibration-Resistant Connection: Properly installed inserts form captive threads that help resist rotation and loosening.
Organized Kit Storage: Molded carrying case keeps the setting tool, mandrels, nosepieces, inserts, and wrench arranged and protected.
Product Name: Marson Aluminum Klik Thread-Setter Kit w/Inserts & M39300 Tool (39313)
Model Number: 39313
Included Tool: M39300 manual Thread-Setter
Insert Capacity: 62 aluminum Klik Thread-Serts
Supported Thread Sizes: #6-32, #8-32, #10-24, #10-32, 1/4-20, 5/16-18, and 3/8-16
Insert Material: Aluminum
Operation Type: Manual lever action
Included Installation Hardware: Compatible mandrels and nosepieces for the supported thread sizes
Included Adjustment Tool: One operator wrench
Case Type: Molded storage and carrying case
Product Weight: 2 lb
Package Contents: One M39300 tool, mandrels and nosepieces, 62 aluminum inserts, one operator wrench, and one molded storage case
Choose the Insert: Select the threaded insert that matches the required bolt or screw size.
Prepare the Mounting Hole: Drill a correctly sized hole in the workpiece and remove any burrs, dirt, or debris.
Select the Tooling: Choose the mandrel and nosepiece that correspond to the selected insert size.
Configure the Tool: Install the mandrel and nosepiece onto the M39300 tool using the supplied wrench.
Load the Insert: Thread the aluminum insert onto the mandrel until its flange rests against the nosepiece.
Position the Insert: Place the insert completely into the prepared hole with its flange seated against the material surface.
Set the Insert: Squeeze the tool handles firmly to compress the insert body against the reverse side of the workpiece.
Check the Installation: Confirm that the insert is securely seated, properly aligned, and unable to rotate inside the hole.
Release the Tool: Rotate the mandrel knob to unthread the tool from the installed insert.
Attach the Component: Position the required component and secure it using a compatible bolt or machine screw.
Benefits of Using Marson Aluminum Klik Thread-Setter Kit w/Inserts & M39300 Tool (39313):
Reduces Installation Time: Allows a single operator to create threaded attachment points without welding or rear-side hardware.
Protects Finished Surfaces: Compression-based installation minimizes the heat, marking, and distortion associated with other fastening methods.
Creates Threads in Thin Materials: Provides secure thread engagement where the substrate lacks sufficient thickness for conventional tapping.
Supports Removable Components: Permanent inserts allow attached parts to be bolted, removed, and reinstalled as required.
Accommodates Multiple Applications: Seven supported imperial thread sizes cover a broad range of repair, fabrication, and assembly requirements.
Improves Joint Reliability: Controlled insert deformation creates a stable mounting point designed to resist spinning and pull-out.
Seven-Size Imperial Assortment: Includes installation components for commonly used coarse and fine thread configurations.
Compact Hand-Tool Profile: Manual design supports installation in confined spaces and restricted work areas.
Interchangeable Component System: Replaceable mandrels and nosepieces allow efficient transitions between supported insert sizes.
Dedicated Service Wrench: Supplied hand tool simplifies the removal, installation, and tightening of setup components.
Lightweight Aluminum Fasteners: Included inserts add minimal weight while creating reusable threaded attachment points.
Repeat-Installation Capability: Tool configuration supports multiple inserts of the same size without requiring adjustment before every installation.
Compartmentalized Carrying Case: Dedicated storage areas help protect small components and simplify inventory management.
Product identification
- Brand: Marson
- Model / MPN: M39313
