JET L100-150-70 202670 1.5 Ton Chain Hoist, 70 ft
The JET L100-150-70 202670 combines a 1.5 ton rated capacity with a 70 ft lift configuration. It is operated by hand chain, making operating-chain reach a separate ordering check from the distance the load hook can travel.
Specifications and included details
- L100-150-70, part 202670: 1.5 ton capacity and 70 ft lift.
- Manual hand-chain operation with listed overload protection.
- Grade 100 plated load chain and a heavy-duty steel frame.
- Weston-style double-ratchet-pawl brake and double-sealed ball bearings are listed.
- Industrial alloy steel swivel hooks are listed.
Before ordering
Verify supplied hand-chain length, installed headroom and the manufacturer's permitted hook orientation before ordering this long-lift configuration. Check the capacity marking and complete overhead support system. Do not use the generic lowering text as an operating procedure; follow the model manual.
Product questions and answers
Does a 70 ft lift specify how far the operator can reach?
No. Lift describes load-hook travel. The supplied hand-chain length and its usable position need separate confirmation for your installation.
Is L100-150-70 a one-ton hoist?
No. This product identifies a 1.5 ton capacity. Check the manufacturer's rating and units rather than choosing it from a generic one-ton search phrase.
Does a swivel hook make every pulling angle acceptable?
No. A swivel feature does not establish permission for side loading or an arbitrary load angle. Use the manufacturer's rigging and hook-seating instructions.
