Jet JCT-1602 800 BPM Benchtop Sand Rammer (550602)
Jet JCT-1602 800 BPM Benchtop Sand Rammer (550602) is a heavy-duty pneumatic tool engineered for the efficient compaction of sand in various applications. Its robust construction and powerful performance make it a reliable choice for industrial settings like foundries, pipework, and cable trenching. This rammer is designed to tackle small, medium, and large molds with ease, thanks to its fast, powerful blows delivered at 800 per minute.
KEY FEATURES AND BENEFITS
Increased Durability: The all-steel cylinder housing ensures the rammer withstands rigorous use, reducing downtime and replacement costs.
Fast and Powerful Compaction: With 800 blows per minute, this rammer quickly and efficiently compacts sand, saving valuable time in production processes.
Extended Tool Life: The front-end seal protects the piston from dirt and debris, extending the tool's lifespan and minimizing maintenance requirements.
Industry-Proven Design: The heavy-duty valve design has been proven reliable in industrial applications, ensuring consistent performance and longevity.
Stock Number: JT9-550602
Air Consumption: 24 CFM
Air Hose (ID): 3/8 in.
Air Inlet (NPT): 3/8 in.
Air Pressure: 90 PSI
Blows Per Minute: 800
Bore Size: 1 in.
Butt Diameter: 2-9/16 in.
Model Number: JCT-1602
Overall Length: 19-11/16 in.
Piston Stroke: 3-15/16 in.
Taper: 1.39 degrees
Vibration Value: 32.49 m/s²
Weight: 13.23 lbs
Gross Weight: 15 lbs
Preparation: Ensure the work area is clean and free of debris. Connect the air hose from your compressor to the rammer's air inlet.
Starting: Set the desired air pressure on your compressor, typically 90 PSI for this model.
Operation: Hold the rammer firmly with both hands. Position the butt end of the rammer on the sand you want to compact.
Ramming: Activate the rammer by depressing the trigger. Allow the rammer to do the work; excessive force is not necessary.
Moving: Lift the rammer and reposition it to the next area you need to compact. Continue until the entire area is compacted.
Stopping: Release the trigger to stop the rammer. Disconnect the air hose after use.
BENEFITS OF USING JET JCT-1602 800 BPM BENCHTOP SAND RAMMER (550602)
Improved Productivity: Faster compaction speeds mean more work completed in less time.
Reduced Operator Fatigue: Ergonomic design and lightweight construction minimize strain on the user.
Consistent Results: Reliable performance ensures uniform compaction of sand for high-quality finished products.
Versatility: Suitable for a wide range of applications, from small molds to larger projects.
All-steel cylinder housing for increased durability.
Fast, powerful blows for compacting small, medium, and large sand molds.
Front-end seal protects the piston from debris, extending tool life.
Heavy-duty, industry-proven valve design.
Product identification
- Brand: Jet
- Model / MPN: 550602
