Jet JCT-1601 1000 BPM 2-9/16" Stroke Benchtop Sand Rammer (550601)
The Jet JCT-1601 1000 BPM 2-9/16" Stroke Benchtop Sand Rammer (550601) is a heavy-duty tool designed for efficiently compacting sand molds in casting and foundry operations. Its powerful blows and durable construction make it ideal for various mold sizes.
KEY FEATURES AND BENEFITS:
Powerful and efficient: Delivers fast, strong blows for optimal sand compaction.
Durable construction: All-steel cylinder housing ensures long-lasting performance.
Protection: Front-end seal protects the piston from dirt and debris, extending tool life.
Reliable performance: Heavy-duty, industry-proven valve design for consistent operation.
Ergonomic design: Comfortable handle reduces operator fatigue.
Easy maintenance: Simple design for quick cleaning and inspection.
Model Number: JCT-1601
Stock Number: JT9-550601
Air Consumption (CFM): 17.0000
Air Hose (ID/In.): 3/8
Air Inlet (NPT): 3/8
Air Pressure (PSI): 90
Blows Per Minute: 1000
Bore Size (In.): 6/7
Butt Diameter (In.): 2-3/64
Overall Length (In.): 14-1/2
Piston Stroke (In.): 2-9/16
Taper (Deg.): 1.38
Vibration Value (m/s²): 33.8400
Weight (Lbs.): 6.5
Gross Weight: 7.5
Connect the air hose to the rammer's air inlet and ensure a secure connection.
Turn on the compressed air supply and adjust the pressure to the recommended 90 PSI.
Hold the rammer firmly with both hands, ensuring a secure grip on the handle.
Position the rammer above the sand mold, maintaining a perpendicular angle.
Activate the rammer by pressing and holding the trigger.
Apply steady pressure to the rammer as it compacts the sand.
Move the rammer in a systematic pattern, covering the entire mold area.
Continue the process until the desired sand compaction is achieved.
Once finished, turn off the compressed air supply and disconnect the air hose.
Clean the rammer thoroughly to remove any sand or debris.
BENEFITS OF USING JET JCT-1601 1000 BPM 2-9/16" STROKE BENCHTOP SAND RAMMER (550601):
Improved mold quality and consistency
Increased production efficiency
Reduced labor costs
Enhanced worker safety
Longer tool life due to durable construction
All-steel cylinder housing
Fast, powerful blows
Front-end seal protection
Heavy-duty valve design
Ergonomic handle
Product identification
- Brand: Jet
- Model / MPN: 550601
