Iwata RG3L-3 2866 Round-Pattern Gun with PC61 Cup
The RG3L-3 package is a detail-oriented round-pattern gun with a 1.0 mm nozzle and included PC61 side-mounted cup. Its 130 ml capacity and listed 35 mm pattern width distinguish it from the wider-fan LPH300 setups. The main photograph shows the cup alone; the written package inventory identifies both gun and cup.
Specifications and included details
- Model: RG3L-3; part number: 2866.
- 1.0 mm fluid nozzle and round spray pattern.
- Included PC61 130 ml stainless steel side-mounted gravity cup.
- Listed air consumption: 50 L/min.
- Listed recommended pressure: 0.24 MPa / 2.4 bar.
- Listed fluid output: 80 ml/min; pattern width: 35 mm.
Before ordering
Match the narrow round pattern to the intended detail work and verify available airflow and pressure measurement conditions in the Iwata manual. Confirm coating and cup compatibility. Cup rotation does not by itself establish uninterrupted inverted spraying; use the manufacturer's orientation and filling limits.
Product questions and answers
Is this a wide-fan gun for covering large panels?
The specified pattern is round with a listed 35 mm width. Choose it around detail work rather than assuming the wide fan of a larger gun.
Does the cup-only main photo mean the gun is excluded?
No. The written package inventory identifies the RG3L-3 gun and PC61 130 ml stainless steel cup.
Can I spray upside down just because the side cup rotates?
Do not assume that from rotation alone. Check the manufacturer's permitted orientation and cup-fill limits for the actual material.
