Iwata LPH440-141 5723 Primer Gun with 1000 ml Cup
The 5723 package is a 1.4 mm LPH440-141 primer gun with a one-liter aluminum gravity cup. Its primer/sealer focus distinguishes it from LVX basecoat packages, even where the cup image appears similar. Select it around the coating's nozzle and gun requirements; a primer-gun designation does not establish suitability for every high-build filler.
Specifications and included details
- LPH440-141 model; code: 5723.
- 1.4 mm nozzle.
- HVLP gravity feed.
- Primer and sealer uses described.
- Included PCG10EM 1000 ml aluminum cup.
- Listed pattern width: 9.8 inches.
Before ordering
Confirm coating viscosity, gun/nozzle requirements and model-specific airflow and pressure conditions. The provided text does not itemize compressor CFM. Use the manufacturer's instructions instead of applying a generic primer setting, and do not infer fixed runtime or reduced sanding time from cup size or marketing claims.
Product questions and answers
Is this an LVX basecoat gun package?
It is identified as LPH440-141 for primer and sealer applications. Match the coating requirements rather than choosing by a similar cup photo.
Is the one-liter aluminum cup included?
Yes. The inventory lists the gun with a PCG10EM 1000 ml aluminum cup, although the main photo shows the cup alone.
Does a 1.4 mm primer gun accept every high-build material?
No universal material fit is established. Follow the specific primer or filler technical data and Iwata's gun requirements.
