Irwin 1-7/16" Adjustable Guide Die Stock Handles (12436)
The Irwin 1-7/16" Adjustable Guide Die Stock Handles (12436) is a specialized threading tool engineered to deliver precision and accuracy in every application. This die stock handle is designed to work with 1-7/16" hexagon dies, making it a critical component for anyone involved in creating, repairing, or maintaining threaded parts. Its core functionality revolves around its ability to ensure perfectly straight threads, a common challenge in threading operations.
KEY FEATURES AND BENEFITS:
Precision Threading Alignment: The adjustable guide ensures the die remains perfectly aligned with the workpiece, preventing crooked threads and ensuring a professional finish every time.
Secure Die Locking: A set screw securely holds the die in place, eliminating slippage and wobble during the threading process for a more stable and controlled operation.
Enhanced Durability: Made from high-quality steel, this die stock handle is built to withstand repeated use and provides a long-lasting, reliable performance.
Versatile Compatibility: Specifically designed for 1-7/16" hexagon dies, making it an ideal tool for a range of specific threading applications.
Improved Control and Grip: The handle provides a firm and comfortable grip, allowing for better leverage and control, which is essential for cutting clean and accurate threads.
Die Outside Diameter Compatibility: 1-7/16 inches
Measurement System: Imperial
Materials: Steel
What's Included: 1 pc. Irwin 1-7/16" Adjustable Guide Die Stock Handle
Insert the Die: Place your 1-7/16" hexagon die into the central opening of the die stock handle. Ensure the die is seated flat and correctly positioned.
Lock the Die: Tighten the set screw located on the side of the handle. This will secure the die firmly in place, preventing it from rotating or shifting during use.
Adjust the Guide: Loosen the guide screws on the handle. Slide the adjustable guide so that it makes firm contact with the workpiece, ensuring the die is perfectly aligned and centered.
Begin Threading: Apply downward pressure and begin rotating the die stock handle. For best results, rotate the handle clockwise (for right-hand threads), and periodically turn it counter-clockwise to break the chips and clear the threads.
Remove the Tool: Once the desired thread length is achieved, carefully remove the die stock handle from the workpiece.
BENEFITS OF USING IRWIN 1-7/16" ADJUSTABLE GUIDE DIE STOCK HANDLES (12436):
Professional Results: The adjustable guide system ensures threads are cut perfectly straight, resulting in high-quality, professional-looking work.
Reduced Waste: By preventing misaligned or crooked threads, this tool minimizes errors and the need to discard materials due to mistakes.
Time Efficiency: The stable and secure setup allows for faster and more efficient threading, as less time is spent correcting errors or realigning the tool.
Enhanced Safety: The secure grip and stable design reduce the risk of the tool slipping, providing a safer working experience.
Long-Term Value: The steel construction ensures the tool will last through countless projects, providing a reliable solution for years to come.
Adjustable guide mechanism for maintaining alignment
Steel construction for strength and longevity
Designed for 1-7/16" hexagon dies
Set screw for locking the die securely
Provides a stable and controlled grip during operation
Designed for creating or repairing external threads
Imperial measurement system compatibility
Ergonomic design for user comfort and control
Product identification
- Brand: Irwin
- Model / MPN: 12436
