Grizzly Industrial 3/4 HP Tool Post Grinder (T27400)
Grizzly Industrial 3/4 HP Tool Post Grinder (T27400) is the perfect addition to your lathe for achieving precision grinding and superior surface finishes. Designed for internal and external grinding applications, this grinder excels in handling work-hardened materials and maintaining tight tolerances on long shafts. With a powerful motor and robust build, it's ready to tackle your most demanding projects.
Equipped with interchangeable spindles and fine vertical height adjustment, the Grizzly Tool Post Grinder ensures versatility and adaptability for various lathe setups.
Specifications and Dimensions
Motor: 3/4 HP, 220V, single-phase, 3.5A
Lathe sizes: 12" – 22" swing
External wheel: 3/4" W x 6" D x 5/8" Bore
External wheel speed: 4500 RPM
Internal wheel: 3/4" W x 3/4" L x 1/4" (6mm)
Internal wheel speed: 18,500 RPM
Mounting hole: 25mm D x 37mm L (slotted)
Overall size: 15" L x 12" W x 10" H
Key Features and Benefits
Fine vertical height adjustment for precision
Interchangeable spindles for internal and external grinding
Diamond-tipped dresser for accurate wheel maintenance
60-grit aluminum-oxide grinding wheels included
Designed to fit 12" – 22" swing lathes
Product identification
- Brand: Grizzly Industrial
- Model / MPN: T27400
