Grizzly Industrial 2-Axis Mill DRO System
Grizzly Industrial 2-Axis Mill DRO System features reliable linear optical scales for accuracy and an intuitive DRO readout with advanced functionality, including pitch circle diameter (PCD), inclined machining, and line hole positioning capabilities.
The DRO units are built with sealed aluminum housings and solvent-resistant polyester films to ensure durability in demanding environments. Scales are equipped with smooth-sliding mechanisms using P5-grade bearings and high-resolution measurements for seamless operation.
Specifications and Dimensions
T32997: Scale travel lengths: 5-15/16", 13-13/16", Accuracy: ±6μm
T32998: Scale travel lengths: 5-15/16", 19-11/16", Accuracy: ±6μm
T33003: Scale travel lengths: 7-7/8" and 17-3/4", Accuracy: ±6μm
T33004: Scale travel lengths: 7-7/8", 19-11/16", Accuracy: ±6μm, ±10μm
T33006: Scale travel lengths: 7-7/8", 21-11/16", Accuracy: ±6μm, ±10μm
T33007: Scale travel lengths: 7-7/8", 23-5/8", Accuracy: ±6μm, ±10μm
T33010: Scale travel lengths: 9-7/8", 23-5/8", Accuracy: ±6μm, ±10μm
T33014: Scale travel lengths: 11-13/16", 29-9/16", Accuracy: ±6μm, ±10μm
T33016: Scale travel lengths: 13-13/16", 29-9/16", Accuracy: ±6μm, ±10μm
T33019: Scale travel lengths: 15-3/4", 31-1/2", Accuracy: ±6μm, ±10μm
Supply voltage: DC 5V
Optical period: 20μm
Optical measurement: Transmissive infrared
Repeatability: 2μm
Seal protection: IP53
Key Features and Benefits
Advanced readout functions: PCD, LHOLE, INCL, radius calculation, and more
Durable, sealed aluminum casing with solvent-resistant polyester film
High-precision scales with smooth sliding motion using P5-grade bearings
Product identification
- Brand: Grizzly Industrial
