Brandmotion Universal Snap-In Adjustable Bullet Camera (BRM9002-7612)
The Brandmotion Universal Snap-In Adjustable Bullet Camera (BRM9002-7612) is engineered to provide a discreet and reliable visual aid for safe maneuvering and parking. Its bullet-style design and snap-in mounting method make it a practical solution for vehicles where traditional mounting styles are not suitable. Designed for installation directly onto a flat surface such as a bumper or body panel, this camera delivers versatility and optical quality through its high-grade CMOS sensor, wide 150° horizontal field of view, and fully adjustable head for optimal placement.
KEY FEATURES AND BENEFITS:
Discreet bullet-style design with snap-in mounting for easy installation.
Equipped with a high-quality CMOS sensor for clear, color images.
Wide field of view: 150° horizontal and 100° vertical coverage.
Automatic white balance and electric auto iris for consistent image quality in various lighting.
Adjustable camera head to secure the optimal viewing angle.
Switchable parking gridlines and image mirroring for flexible rear or front use.
Durable IP68 waterproof rating for all-weather performance.
Model Number: 9002-7612
Camera Sensor: High Quality CMOS
Resolution: 648×488 pixels (420p)
Field of View (Horizontal): 150°
Field of View (Vertical): 100°
Low Light Sensitivity: 0.5 Lux
Video Format: NTSC
Operating Voltage: 9V–16V
Weather/Waterproof Rating: IP68
Harness Length: 22 ft chassis harness (RCA connection)
Included Accessories: Snap-In Adjustable Bullet Camera, 22 ft Chassis Harness, Power Harness, Hole Saw, Camera Adjustment Tool
Determine Placement: Select a flat surface (e.g., bumper or body panel) with at least 1.5″ × 1.5″ of space for mounting.
Prepare Mounting Hole: Use the included hole saw to drill the required hole at the chosen location.
Configure Camera Options: Adjust parking gridlines or mirroring by cutting the designated wire loops on the harness.
Install the Camera: Insert the camera into the prepared hole until the snap-in mount locks securely.
Adjust Viewing Angle: Use the provided adjustment tool to set the camera head for the best viewing angle.
Route Wiring: Run the 22 ft chassis harness to the display unit and connect the RCA output to the monitor input.
Apply Power: Connect the power harness to a switched power source (reverse light or ignition).
Test Operation: Activate the display to confirm the camera angle, image quality, and settings.
BENEFITS OF USING BRANDMOTION UNIVERSAL SNAP-IN ADJUSTABLE BULLET CAMERA (BRM9002-7612):
Improved Safety: Wide viewing angle minimizes blind spots during parking and reversing.
Parking Assistance: Optional gridlines provide visual distance and alignment guidance.
Discreet Design: Compact snap-in camera blends with the vehicle’s exterior.
Flexible Viewing: Adjustable lens ensures the best possible angle for each installation.
Weather Resistant: IP68 waterproof rating for reliable all-weather use.
Versatile Application: Can function as a rear or forward-facing camera.
Clear Imaging: High-quality CMOS sensor with stable color reproduction.
Adaptive Performance: Automatic white balance and electric auto iris for lighting adjustments.
Low-Light Capability: Operates effectively at 0.5 Lux for night or dim areas.
Compact Build: Bullet-style design for seamless integration with minimal exposure.
Secure Mounting: Simple snap-in system for hassle-free installation.
Voltage Compatibility: Operates within 9V–16V vehicle electrical systems.
Broad Compatibility: RCA composite video output supports most aftermarket displays.
Product identification
- Brand: Brandmotion
- Model / MPN: BRM9002-7612
