Autel BT508 App-Based Battery and System Tester
The Autel BT508 uses an iOS or Android app to display battery and electrical-system test results. Its 6V/12V battery-test scope is separate from the listed 12V/24V cranking and charging-system checks, so choose the intended procedure explicitly.
Specifications and included details
- 6V and 12V battery testing with 100–2000 CCA range.
- 12V and 24V cranking/charging-system checks identified.
- CCA, CA, SAE, EN, IEC, DIN, JIS and MCA rating systems listed.
- Bluetooth VCI identified for battery and electrical-component registration.
Before ordering
Match battery type, rating standard and voltage to the permitted test mode. Confirm current phone/app compatibility and exact vehicle registration support. A system-test voltage is not a direct battery-test voltage entitlement.
Product questions and answers
Is direct 24V battery testing established?
The listed battery tests are 6V and 12V. The 24V figure refers to cranking/charging-system checks.
Does battery testing guarantee registration support for my vehicle?
No. Battery analysis and vehicle-specific registration are separate functions requiring coverage verification.
Is the phone shown with the tester included?
No included phone is established. A compatible mobile device is required for the app-based workflow.
