ALLSTEEL Carbide Burr SM-5, Double Cut (01W318)
ALLSTEEL 01W318 Carbide Burr SM-5, Double Cut is built for high-performance cutting and surface removal in severe applications. Featuring the SM-5 oval shape and double cut geometry, this burr enables smooth, controlled grinding from the tip to the base. The exclusive design maximizes usable surface area, enhancing cutting efficiency and operator control. Ideal for use on a wide range of metals, including steel and stainless steel, this burr is suited for aggressive deburring, surface preparation, and material shaping tasks.
SM-5 oval shape for versatile contouring and surface blending.
Double cut style ensures fast, smooth material removal.
Exclusive geometry for full-use cutting surface from tip to base.
Solid carbide head offers superior wear resistance and durability.
Brazed shank ensures minimal vibration and excellent control.
High material removal rate for improved productivity.
Reduces hand fatigue with smooth, vibration-free cutting.
Maximizes operator safety and precision during use.
Ideal for challenging applications on tough materials.
Delivers reliable results in demanding metalworking environments.
Technical Specifications:
Burr Style: SM-5
Cut Type: Double Cut
Head Diameter: 1/2 inch
Shank Diameter: 1/4 inch
Overall Length: 2-1/2 inches
Application: High-efficiency material removal on metals
Construction: Solid carbide head with brazed shank
Product identification
- Brand: ALLSTEEL
- Model / MPN: 01W318
