AIMS Power 1000W 12V DC Pure Sine Wave Inverter (PICOGLF10W12V120V)
AIMS Power 1000 Watt Pure Sine Low-Frequency Inverter Charger (PICOGLF10W12V120V) is a versatile, high-performance power solution designed for small industrial applications, off-grid backup power, and recreational use. Perfect for powering essential appliances during emergencies, this inverter charger is ideal for off-grid homes, solar systems, RVs, boats, campsites, and tailgating events. This inverter charger can be used globally, thanks to its auto-frequency detection. It features a dual GFCI outlet, battery priority mode, and low-voltage shutdown to protect your batteries. Whether you need a reliable off-grid solution or a backup power source for your business, home, or RV, this AIMS Power inverter is designed to provide consistent, safe, and efficient power.
1000W continuous output, 3000W surge (20 seconds)
Battery priority selector for direct battery use
35A multi-stage smart charger for gel, AGM, and LiFePO4 batteries
Marine-coated for protection against corrosion
GFCI outlet (10A), ideal for safety
Auto frequency detection for worldwide use
Power saver mode with 25W hibernation
Selectable 7 battery type settings for optimal charging
Optional remote panel for convenient operation
Automatic transfer switch with 10ms transfer time
Inverter Output:
Continuous Output Power: 1000W
Surge Rating: 3000W (20 seconds)
Output Waveform: Pure Sine (Bypass Mode)
Nominal Efficiency: >88%
Line Mode Efficiency: >95%
Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
Typical Transfer Time: 10ms
Input Specifications:
Nominal Input Voltage: 12.0VDC
Minimum Start Voltage: 10.0VDC
Low Battery Alarm: 10.5VDC–11.0VDC
Low Battery Trip: 10.0VDC–10.5VDC
High Voltage Alarm: 16.0VDC
Low Battery Voltage Restart: 13.3VDC
Idle Consumption: < 12.5W
Power Saver Mode Idle Consumption: < 7.5W
Charger Specifications:
Output Voltage: Depends on Battery Type
Charger Rate: 35A
Overcharge Protection: 15.7V
Charge Current Adjustability: Off, 20%, 100%
Four-Stage Smart Charger
Transfer Switch:
30A Automatic Transfer Switch
Transfer Time: 10ms (max)
Dimensions & Weight:
Unit Weight: 35 lbs
Unit Dimensions (L x W x H): 14.1 x 8.74 x 7.10 inches
Product identification
- Brand: Aims Power
- Model / MPN: PICOGLF10W12V120V
