Shop press details
100-ton Capacity Heavy-Duty Shop Press
1857 – 100-ton press. Includes single-acting
No. 52434 ram with 10" stroke; No. 4008 hydraulic
hand pump; No. 9651 gauge; No. 9781 hose
(3/8" ID x 10'); and pump mounting bracket.
1858 – Same as No. 1857, except has double-acting No. 51683 ram with 13" stroke;
No. 61217 3-phase, 220V, 3450 rpm electric/hydraulic pump; and two No. 9769 hoses.
1858-1P – Same as No. 1858, except it has a No. 4064 2-stage, 1-phase hydraulic pump.
Wide open uprights allow easy positioning of bars
and shafts for straightening or bending.
Upper bolster can be lowered for convenient
positioning during repetitive jobs.
Ram head glides smoothly on rollers for easy
horizontal adjustments; rugged press frame will
withstand a full capacity load with the ram head in
any position across the upper bolster.
Product identification
- Brand: OTC
